What is Knob and Tube Wiring?

Knob and tube was the standard electrical system that was used from 1880 to 1930.  Ceramic knobs were secured into wall studs or floor joists – these knobs were used as anchors for the wiring. The wiring was then fed through ceramic tubes that were cut into wall studs and flooring. In was by running the wires through these tubes, electricians could avoid direct contact between the wires and the wood.

Why is knob and tube wiring no longer used?

Knob and tube wiring is no longer an acceptable practice for a few reasons. Firstly the installation required the wires to be open to dissipate heat from conductivity.  Secondly it was a very costly method of installation as the price of electricians increased over the years.  Modern materials/wiring practices over the years would become much easier and safety.

Knob Tube Wiring 2

Is knob and tube wiring dangerous?

This method of wiring was seen to be safe at the time of installation and used for many years.  Technically, it could still be used in modern application and be functional, but would not be practical or cost efficient for current requirements.

Knob and tube wiring isn’t dangerous by itself, but if you have knob and tube in your home, there’s definitely a risk. Knob and tube wiring is dangerous because it’s old – that means a number of safety precautions that exist in modern systems won’t be present. Old knob and tube wiring wasn’t grounded and didn’t use multi-switching, which can lead to serious potential fire and shock hazards.

Modern home buyers often discover existing Knob & Tube systems will be insufficient for today’s levels of power consumption. These outdated wiring techniques became susceptible to overloading by homeowners.  This overloading of the electrical circuits created a higher risk of fire hazards.

Knob-and-tube wiring may also be damaged by building renovations. Its cloth and rubber insulation can dry out and turn brittle. It may also be damaged by pests and careless activities such as hanging objects from wiring running in accessible areas like basements or attics. Having a proper home inspection will help identify the potential presence of knob and tube wiring.

What to do if you think you have Knob & Tube Wiring? Insurance Implications?

You must disclose the presence of knob and tube wiring to your insurance companies.  Sometimes you will have to pay an additional premium for the presence of active knob and tube.  As existing knob & tube wiring gets older, insurance companies may deny coverage due to a perception of increased risk. Home inspections by qualified companies like Inspection Services Group Inc will help mitigate risk.

Internachi Suggestions:

  • Have the system evaluated by a qualified electrician or the Electrical Safety Authority. Only an expert can confirm that the system was installed and modified correctly.
  • Do not run an excessive amount of appliances in the home, as this can cause a fire.
  • Replace all outlets with ground fault circuit interrupter (GFCI) outlets. These are 3-prong outlets with a built-in reset button.
  • Where the wiring is brittle or cracked, it should be replaced. Proper maintenance is crucial.
  • K&T wiring should not be used in kitchens, bathrooms, laundry rooms or outdoors. Wiring must be grounded in order to be used safely in these locations.
  • Rewiring a house can take weeks and cost thousands of dollars, but unsafe wiring can cause fires, complicate estate transactions, and make insurers skittish.
  • Homeowners should carefully consider their options before deciding whether to rewire their house.
  • The homeowner or an electrician should carefully remove any insulation that is found surrounding k&t wires.
  • Prospective home buyers should get an estimate of the cost of replacing k&t wiring. They can use this amount to negotiate a cheaper price for the house.
  • Modern home buyers often find that existing K&T systems lack the capacity for today’s levels of power use. First-generation wiring systems became susceptible to abuse by homeowners who would replace blown fuses with fuses rated for higher current. This overfusing of the circuits subjects wiring to higher levels of current and risks heat damage or fire.
  • Knob-and-tube wiring may also be damaged by building renovations. Its cloth and rubber insulation can dry out and turn brittle. It may also be damaged by pests and careless activities such as hanging objects from wiring running in accessible areas like basements or attics.
  • Currently, the National Electrical Code forbids the use of loose, blown-in, or expanding foam insulation over K&T wiring. This is because K&T is designed to let heat dissipate to the surrounding air. As a result, energy efficiency upgrades that involve insulating previously uninsulated walls usually also require replacement of the wiring in affected homes.
  • As existing K&T wiring gets older, insurance companies may deny coverage due to a perception of increased risk. Several companies will not write new homeowners policies at all unless all K&T wiring is replaced, or an electrician certifies that the wiring is in good condition. Also, many institutional lenders are unwilling to finance a home with the relatively low-capacity service typical of K&T wiring, unless the electrical service is upgraded.  Partial upgrades, where low demand lighting circuits are left intact, may be acceptable to some insurers.

The post Knob and Tube Wiring appeared first on Inspection Services Group.

]]>
https://inspectionservicesgroup.com/knob-and-tube-wiring/feed/ 0 1488
Should I buy a home with aluminum wiring? https://inspectionservicesgroup.com/should-i-buy-a-home-with-aluminum-wiring/ https://inspectionservicesgroup.com/should-i-buy-a-home-with-aluminum-wiring/#respond Sun, 29 Jan 2023 02:00:35 +0000 https://inspectionservicesgroup.com/?p=1296 A lot of the time, our clients that are buying a property with aluminum wiring ask for our professional opinions on if the wiring should be replaced. The common misconception about aluminum wiring is that the product itself is not safe, and insurance and mortgage companies typically treat it as a high-risk installation. Aluminum wiring is in fact a safe ...

The post Should I buy a home with aluminum wiring? appeared first on Inspection Services Group.

]]>
A lot of the time, our clients that are buying a property with aluminum wiring ask for our professional opinions on if the wiring should be replaced. The common misconception about aluminum wiring is that the product itself is not safe, and insurance and mortgage companies typically treat it as a high-risk installation. Aluminum wiring is in fact a safe type of wiring (if installed safely and according to ESA requirements) and it is still used to this day in specific electrical applications.

When was aluminum installed in residential homes?

Aluminum wiring was used throughout the 1970s due to the increasingly high costs of copper. However, after a decade of use in residential properties, some concerns began to rise due to house fires. It was at that time that steps were implemented to ensure that installations were completed safely.

What were the problems with aluminum?

  1. Aluminum wiring was not as conductive as copper and would have to be installed as a larger gauge of wiring. Wires would expand and contract when heated up and had the potential to come loose from the terminals.  In some cases, the wiring would overheat and start fires, therefore, causing damage to homes.
  2. Older aluminum wiring would become brittle and break making it difficult for electricians to work with.
  3. Oxidation became an issue; wiring that was exposed to moisture would take on a white color and lose its conductivity.
  4. Connections at outlets and in the panels would become increasingly dangerous over time.  This was often from poor electrical work or incorrectly rated equipment.
  5. Aluminum and copper cannot be connected together without using special connectors.
Scorched Outlet
Aftermath of a “copper only” outlet connected to aluminum wiring. It nearly set the house on fire

Aluminum & insurance

Insurance Policies were changed over time to reflect aluminum wiring in homes as a potential fire hazard.  In Ontario, a qualified and approved Electrical Contractor should always review the home’s electrical system and provide the homeowner with a Certificate of Acceptance.  We strongly advise keeping a copy of this certificate by your panel for future inspections, along with a copy for your records. Many insurance companies require an updated Certificate for renewal purposes.

For more information click here.

How do you know if you have aluminum wiring in your home?

One of the easiest ways to verify what type of wiring is present is to look at the sheathing or wiring casing. It will have either “aluminum” or “al” written on it. If nothing is visible then you have to find a connection in a junction box or in the panel. Additionally, aluminum wiring has a distinct sliver/grey colour, but be sure not to confuse this with older tinned copper. That is why it is important to determine the age of the home. If it was built in the late 1960s or 1970s then chances are it will be aluminum.

Aluminum wire

What is the solution?

The most expensive and impractical correction is to rewire the home with copper wiring. This is not a requirement for safety but sometimes is the case for alarmed home buyers. The more common solution is to perform a procedure called “pig tailing,” which involves using AL-CU-rated marrets at respective receptacles and light fixtures. This type of repair can cost $100 per outlet for repairs. The wiring should also have an anti-oxidation paste to prevent corrosion of the wires. By utilizing these safe practices, you can ensure your wiring is safe. Do not attempt to do this procedure on your own, instead, always talk to a licensed electrical contractor about aluminum wiring installations.

Aluminum wiring

Is it safe to buy a home with aluminum?

The answer to this is simple: if your home has been inspected by a qualified electrical contractor and all the safety protocols have been followed, then your home is safe. The electrical authority in Ontario, Canada says, “Aluminum wiring itself is safe and if proper connections and terminations are made without damaging the wire and using approved materials installed in accordance with the Ontario electrical safety code and the manufacturer’s instructions, there should be no problems with the aluminum wiring installation.”

FAQs

Is there an insurance company that does not require an inspection of the aluminum electrical system in the house?

To our knowledge, no.

Should I have the aluminum wiring checked only to satisfy the insurance company?

No, this is also important for your own safety.

Can I have any electrician do the work and certify it?

No, only an authorized electrical contractor can provide the Certificate of Acceptance.

How much does it usually cost to have the aluminum electrical installation inspected and corrected?

It depends on what needs to be done to correct the issues. Most times, the electrical contractor will require other updates to make the system safe.

Why does the current seller’s insurance company not have any concerns with the aluminum wiring system?

The insurance policy is probably older and does not take into consideration the risk factor. Insurance companies update their policies constantly.

The post Should I buy a home with aluminum wiring? appeared first on Inspection Services Group.

]]>
